Automatic High Effective Medical Ultrasound Bone Densitometer (BMD Machine)

1 / 5

Automatic High Effective Medical Ultrasound Bone Densitometer (BMD Machine)

Customization:	Available
Classification:	Imaging Diagnostic Equipment
Type:	Ultrasound Scanner

Send Inquiry

Product Description

📋

Basic Specifications

Model NO.

JRBMD-A3

Certification

CE, EEC, MSDS, ISO13485

Target Group

All Ages (0-100)

Net Weight

6 Kgs

Transport Package

Carton

Specification

42cm × 34cm × 44cm

Origin

P. R. China

HS Code

9018129900

Production Capacity

2000 units/Month

🔬

Product Description

JRBMD-A3 Automatic High Effective Portable Ultrasound Bone Densitometer

Technical Features:

Full dry technology for convenient diagnostic processes.
Probes utilizing United States DuPont technology for high sensitivity and superior reception.
Optimized ultrasonic frequency at the measuring position for better penetrability and effective signaling.
Ultrasonic axial conduction technology with double emission and double receiving for reliable data.
Innovative algorithms to effectively remove clutter and jamming signals.
Special correction system to minimize system errors and ensure accurate measurement results.
Multipoint access mode with high shield manufacturing for lossless ultrasonic signal transmission.
Multi-race clinical database compatible with European, American, Asian, Chinese, and WHO international standards.
Full English menu and user interface.
First to pass the EMC test with CE and ISO certification.

Performance Parameters:

Measurement Parts: Radius and Tibia.
Measurement Parameters: Speed of Sound (SOS), T-Score, Z-Score, Age percent, Adult percent, BQI (Bone Quality Index), PAB (Physiological age of bone), EOA (Expected Osteoporosis age), RRF (Relative Fracture Risk).
Accuracy & Reproducibility: ≤0.25%.
Measurement Time: < 25 seconds.
Probe Frequency: 1.20MHz.
Navigation System: Real-time display of Axial, Horizontal, and Directional angles to improve measurement speed and accuracy.
Intelligent Analysis: Automatically selects adult or child databases based on age.
Monitor: 10.4' HD color LED monitor.
Fluid Protection: Main unit IPX0, Probe waterproof level IPX7.
Portability: Main unit weight < 4kgs, easy to carry.

📦

Standard Configuration

Ultrasound Bone Densitometer Main Unit
1.20MHz Probe
Embedded Industrial Control Computer
Intelligent Analysis System
Calibrating Module (Perspex sample)
Disinfectant Coupling Agent

Note: Printer is optional.

📷

Product Gallery

Frequently Asked Questions

Q1: Which parts of the body can the JRBMD-A3 measure? The device is specifically designed to measure the bone density at the Radius and Tibia positions.

Q2: How long does a single measurement take? The measurement process is highly efficient, taking less than 25 seconds per session.

Q3: Is this device suitable for pediatric use? Yes, the system includes a multi-race clinical database and automatically switches between child and adult modes for patients aged 0 to 100 years.

Q4: Does the technology require a water bath for scanning? No, it uses full dry technology, making the diagnostic process more convenient and cleaner for both the operator and the patient.

Q5: How accurate are the measurement results? The JRBMD-A3 features a measurement accuracy and reproducibility of ≤0.25%, supported by United States DuPont probe technology.

Q6: Is the device portable for field clinics? Absolutely. The main unit weighs less than 4kg and is designed for high portability and ease of transport.
